GIGABYTE B650M GAMING WIFI

The GIGABYTE B650M GAMING WIFI motherboard delivers high performance and versatility for gamers and PC builders. Designed with the latest technology, it supports AMD Ryzen™ 7000, 8000, and 9000 Series processors. The motherboard features a robust 5+2+2 Phases Digital VRM Solution and offers dual-channel DDR5 memory support. For fast storage and reliable connectivity, it includes a PCIe 4.0 x4 M.2 slot, 2.5GbE LAN, and 802.11ac Wi-Fi. Its sleek design and advanced features make it an excellent choice for high-performance computing.

Key Features

• AMD Socket AM5 Support: Compatible with AMD Ryzen™ 7000, 8000, and 9000 Series processors for enhanced performance.
• 5+2+2 Phases Digital VRM Solution: Ensures stable power delivery with Low RDS(on) MOSFETs, improving system reliability.
• Dual Channel DDR5 Support: Offers 2 SMD DIMMs with AMD EXPO™ and Intel® XMP support for memory speeds up to 6400 MHz.
• SuperSpeed Storage: PCIe 4.0 x4 M.2 connector provides ultra-fast storage performance.
• EZ-Latch PCIe Slot: Features a Quick Release Design for easy installation and upgrades.
• High-Speed Networking: Includes 2.5GbE LAN and 802.11ac Wi-Fi for fast and reliable internet connections.
• Extended Display Connectivity: HDMI and D-sub ports support various display setups.
• Smart Fan 6 Technology: Multiple temperature sensors and hybrid fan headers with FAN STOP keep your system cool.
• Q-Flash Plus: Update the BIOS without needing to install the CPU, memory, or graphics card.
• GIGABYTE Ultra Durable™: Built with high-quality components for long-lasting performance.

Specifications

The GIGABYTE B650M GAMING WIFI motherboard features an AMD Socket AM5, supporting Ryzen™ 7000, 8000, and 9000 Series processors. The chipset is AMD B650, and it supports DDR5 memory up to 6400 MHz (OC), with 2 DIMM slots for up to 128 GB of memory. Integrated AMD Radeon™ Graphics include a D-Sub port and an HDMI port, supporting resolutions up to 4096×2160@60 Hz. The audio is managed by a Realtek® Audio CODEC, providing high-definition 2/4/5.1/7.1-channel sound.

Networking is handled by a Realtek® 2.5GbE LAN chip and AzureWave Wi-Fi AW-CB304NF module, supporting 802.11 a/b/g/n/ac and Bluetooth 4.2. Expansion includes one PCIe x16 slot and one PCIe x1 slot, with PCIe 4.0 x16 and x4 modes available depending on the CPU. Storage options consist of one PCIe 4.0 x4 M.2 connector and four SATA 6Gb/s connectors, with RAID support for NVMe and SATA devices.

USB connectivity includes 2 x USB 3.2 Gen 1 ports and 1 x USB 2.0/1.1 port on the back panel, with additional ports available through internal headers. Internal connectors include a 24-pin ATX main power connector, an 8-pin ATX 12V power connector, and various fan and LED strip headers.

The motherboard measures 24.0 cm x 22.5 cm and supports Windows 10 and Windows 11 64-bit operating systems. It comes with Norton® Internet Security (OEM version) and LAN bandwidth management software. BIOS management is via a 256 Mbit flash with licensed AMI UEFI BIOS.

Conclusion

The GIGABYTE B650M GAMING WIFI motherboard is designed for high performance and reliability. It supports the latest AMD processors and high-speed memory, providing excellent performance for gaming and demanding applications. The motherboard’s fast storage options, high-speed networking, and advanced cooling technology ensure a top-notch computing experience. With its durable build and user-friendly features, the GIGABYTE B650M GAMING WIFI is a great choice for any high-performance PC build.
